| Processor (Speed, L2 Cache, FSB)
Intel® Core™2 Duo processor P8400 (2.26GHz, 3MB L2, 1066MHz FSB, 25watt)
Intel® Core™2 Duo processor P8600 (2.4GHz, 3MB L2, 1066MHz FSB, 25watt)
Intel® Core™2 Duo processor P9500 (2. 53GHz, 6MB L2, 1066MHz FSB, 25watt)
Intel® Core™2 Duo processor T9400 (2.53GHz, 6MB L2, 1066MHz FSB, 35watt)
Intel® Core™2 Duo processor T9600 (2.8GHz, 6MB L2, 1066MHz FSB, 35watt)

Preloaded Operating SystemGenuine Windows Vista® Ultimate 32
Genuine Windows Vista® Business 32
Genuine Windows Vista® Business 64
Genuine Windows Vista® Home Premium 32
Genuine Windows Vista® Home Basic 32
Genuine Windows® XP Professional

Serial ATA Hard Disk Drives
500 GB 5400rpm

MemoryUp to 8GB of PC2-8500 1066MHz DDR3

Optical Drive
DVD-ROM , CD-RW/DVD-ROM , DVD burner, Blu-ray

Keyboard
Ergonomic keyboard with palm rest, ThinkPad UltraNav® multipointing system, including TrackPoint® pointing device with “Press-to-Select”, Internet scroll bar, intuitive volume, ThinkVantage button and Windows® key

Graphics
Integrated Intel® GM 45 Express

Available Integrated Communication
Gigabit Ethernet
Integrated WWAN 2 (with GPS)
Ultra WideBand (UWB) (available later in 2008
Bluetooth® 2.1
WiMAX (available later in 2008)

Supported WLAN cards:
Intel® Wireless WiFi Link 5100 1x2
Intel® Wireless WiFi Link 5300 3x3
Intel® Wi MAX/WiFi Link 5350
ThinkPad 11b/g Wireless LAN Mini PCI Express
Adapter III 7

Security
Standard: ThinkVantage Client Security with password manager, Integrated Trusted Platform Module (TPM v1.2), Bios disable of all ports
Optional: Integrated Fingerprint Reader, SmartCard Reader, Full Disk Encryption HDD, Softex OmniPass, Utimaco® SGE

Other Features
Optional integrated camera, white ThinkLight®

ThinkPad Shock-Mounted Hard Disk Drive
Standard

Included Software (preloaded)
Adobe Acrobat Reader; Microsoft® Office Ready 2007; Microsoft® Windows Live™ Toolbar & Search; Roxio Creator; Intervideo WinDVD (DVD models only); Intervideo WinDVD Creator (DVD models only); McAfee VirusScan® Plus with 30 days of virus definition updates; Creator Business Edition (combo models); Creator Business Edition + MY DVD (DVD Burner); PC -Doctor diagnostics; Sun® JRE™ ; ThinkPad Utilities (Power Manager and Presentation Director); ThinkVantage Access Connections™ ; ThinkVantage Fingerprint Software; ThinkVantage Productivity Center; ThinkVantage Rescue and Recovery; ThinkVantage System Update; ThinkVantage Client Security Solution
|
ThinkPad R400
Li-ion Battery Life (Windows Vista®)
4-cell: starting at 4.3hr
6-cell: starting at 6.5hr
9-cell: starting at 9.8hr
9-cell + bay battery: starting at 13.0hr

Dimensions
335.3x238x27.6x31.9mm (4/6-cell battery)
13.2x9.4x1.1 - 1.3"

Weight
4-cell battery models starting at 2.13kg/4.7 lb

Display
WXGA (1280x800, 98dpi, 185+ nit)
WXGA+ W/LED Backlight (1440x900, 129dpi, 200+ nit)

Ports and Slots
Ports: 3 USB, IEEE 1394a, VGA, Microphone/line-in, Headphone/line-out
Slots: Standard ExpressCard 34/54mm and optional choice of either PC Card, or 7-1 Media Card Reader and optional choice of either PC Card or SmartCard |
ThinkPad R500
Li-ion Battery Life
6-cell: starting at 4.3hr
9-cell: starting at 6.4hr
9-cell + bay battery: starting at 8.5hr

Dimensions
357.5x255 x 29.7x 33.5mm (6-cell battery)
14.1x10.0x1.2 - 1.3"

Weight
6-cell battery models starting at 2.63kg/5.8 lb

Display
WSXGA+ (1680x1050, 129dpi, 200+ nit)
WXGA W/LED Backlight (1280x800, 129dpi, 200+ nit)

Ports and Slots
Ports: 3 USB, IEEE 1394a, VGA , Microphone/line-in, Headphone/line-out, DisplayPort and optional DVI -D monitor cable
Slots: Standard ExpressCard 34/54mm, 7-1 Media Card Reader and optional choice of either PC Card or SmartCard |
