Lenovo Thinkcenter M58 SFF

lenovo ThinkCenter M58 Desktop

ThinkCentre M58 desktops are engineered exclusively for the way you work. Equipped with the Intel® dual or quad-core technology, DDR3 memory and Fast Hard drives, desktop productivity and performance are truly maximized. Lenovo’s leadership in thermals, acoustics and energy efficiency give the M58 and M58p a true edge over the competition. Added to these stand-out qualities are our ThinkVantage Technologies and licensed Intel® vPro™ technologies, intelligently combined to give you the ultimate degree of manageability.

The costs savings associated with Lenovo’s Secure Managed Client are substantial – between 30 and 40% over a well-managed PC over a typical three-year lifecycle. This robust software stack and storage array simplifies your desktop solution with less cost ,  It’s also now dramatically easier for employees to set up

DESIGN INNOVATION

• Innovative ventilation and fan layout provides industry leading acoustics
• Innovative small form factor design provides great ease of-use, serviceability and thermal efficiency, all in a svelte 10L footprint
• New Eco USFF provides a PCI slot, tool-less motherboard and optional PS/2 port
• Robust tower design provides unprecedented expandability and power in a 25L chassis
• Refurbished grade a minus condition (very good) with 1 year warranty parts and labor

MANAGEaBILITY AND STABILITY

• Platform and image stability for up to 15 months
• Global models for easy worldwide deployment
• Latest Intel® iAMT 5.0 vPro™ technology available on all form factors
• Lenovo’s unique Hardware Password Manager(1) provides advanced password management. In addition to a variety of encryption possibilities, this solution features a unique hardware ID. If someone hacks your PC or makes a copy of your hard drive, they won’t be able to crack the program because it works only with your PC – and no other.

SECURITY

• ThinkVantage® Technologies offer Client Security Solution and an optional fingerprint reader
• I/O ports have individual disable/enable capability - Individually manage all I/O ports (including USB ports) through BIOS • TPM (Trusted Platform Module) 1.2 data encryption - Stolen data cannot be read on any other computer
• Ready for Computrace - Locate your stolen PC when it connects to the Internet
• Chassis Intrusion Switch - Sends an alert to the management console when chassis is opened
• PS/2® (2) port available on all form factors - Use PS/2® ports to avoid unauthorized data transfer and provide virus protection from USB peripheral devices

ThinkCentre M58/M58p is thoughtfully designed with a NEW Eco uSFF design that takes up very little space but still allows for easy PCI expandability as well as being one of the most environmentally responsible desktops available:

• PCI slot for simple expansion and connectivity
• Dual Independent Display (DID) support by onboard DisplayPort and VGA
• Tool-less design – remove motherboard, HDD without tools
• 8 external USB ports
• PS/2® port support - Customers can disable each USB port individually - Avoid unauthorized data copy - Avoid virus from USB peripheral devices

ThinkCentre M58/M58p features exciting new technologies for a best-in-class user experience:

• DDR3 memory: 10% faster transfer rate and 25% power savings compared to DDR2
• On-board DisplayPort, the next generation digital display interface standard, is designed to replace DVI, LVDS, and eventually VGA providing higher performance and improved digital display connectivity
• New optional Solid State Drives (SSD)(7) give users six times the reliability improvement and a 37% increase in performance over HDD
• Optional Blu-ray™ ODD(8) enables storing large amounts of data, ten times the capacity of a standard DVD and recording, rewriting and playback of high-definition video (HD)

System board / Form factor

Supports Intel Core™ 2 Duo™ processor with 2MB, 3MB, 4MB or 6MB L2 cache

Processor

Intel Core 2 Duo processor

Chipsets

Intel Q45 core chipset

Memory

• 1066 MHz DDR3 (Double Data Rate) dual channel memory support
• PC3-8500 memory supported
• Uses 512MB, 1GB or 2GB memory modules

Audio

• Integrated Audio Intel Q45
• Front - Audio-Out, Microphone-in
• Rear - Audio-out, Line-in, Microphone-in

Keyboard and mouse

• No keybaord or mouse included

Networking

Intel PRO 100/1000 Gigabit Ethernet

Bays

• One 3.5 inch external accessible bay (FDD)
• Two 3.5 inch internal hidden bay (HDD)
• Two 5.25 inch external half-high bay (optical drives)

External ports

• Eight USB connectors (two on front panel and six on rear panel)
• Two internal high speed USB connectors
• One integrated VGA port
• One integrated Display port
• Ethernet (RJ-45) connector
• Ethernet (RJ-11) connector on selected models
• One standard eSATA connector
• Two audio connectors (microphone in and audio out) on front panel
• Three audio connectors (line in, audio out, and microphone in) on rear panel

Slots

• One half-length, full-height, PCI Express x16
• One half-length, full-height, PCI Express x1
• Two full-length, full-height, 32-bit PCI 2.3 (5v)

Power supply

• 280 Watt
• Operation controlled by a switch on the back of the unit
• 115 to 230 Volt; 50 to 60 Hz

Optical drives available

• DVD-ROM
• DVD Recordable

Operating systems available

• Windows Vista Business 64
• Windows XP
• Windows 7 Pro 64 Bit
• windows 7 Home 64Bit

Hard drive features

• 7200RPM Serial ATA supported

Video cards available

• Intel GMA4500
• HD3470 (RV620 Pro)
• 9500GT 512MB 128BIT ATX (DVI-I+DP)
